MODEL | Li-Cube-48V100AH | Li-Cube-48V150AH | Li-Cube-48V200AH | |||
SPECIFICATION | ||||||
Battery Type | LiFePO4 | |||||
Normal Battery Voltage(Vdc) | 51.2V | 51.2V | 51.2V | |||
Normal Capacity(25℃,0.2C)(WH) | 5120WH | 7680WH | 10240WH | |||
Voltage window (Vdc) | 44.8~58.4V | 44.8~58.4V | 44.8~58.4V | |||
Folat Charge Voltage(Vdc) | 55.2V | 55.2V | 55.2V | |||
Max.continue discharge current(A) | 100 | 150 | 150 | |||
Max.pulse discharge current(A) | 200A 30Sec. | 200A 30Sec. | 200A 30Sec. | |||
Max.continue charge current(A) | 50 | 75 | 100 | |||
Cycle life(+25℃ 0.2C 80%DOD) | >3000 Cycles | |||||
Cell Equalizer Current(A) | 1~5A Max. | |||||
Terminal | M6 | |||||
Storage temperature | 0℃~30℃ | |||||
Storage duration | 6 months at 25℃ | |||||
Safety standard | UN38.3,IEC62619,MSDS,CE | |||||
IP degree | IP20 | |||||
PROTECTION | ||||||
Protection | Overcharge protection、Overdischarge protection、Overcurrent protection、Shortcircuit protection、 Overtemperature protection | |||||
AMBIENT | ||||||
Noise(dB) | < 40dB (1 meter) | |||||
working Temperature | -10℃~+50℃ | |||||
Humidity | 0~95% ( no condensation) | |||||
Sea Level(m) | ≤1500 | |||||
DIMENSION | ||||||
L×W×H (products size) mm | L475*W440*H176mm | L535*W440*H176mm | L590*W483*H178mm | |||
L×W×H (package size) mm | L562*W552*H238mm | L624*W552*H238mm | L638*W552*H238mm | |||
Weight(NW Kg) | 42.0Kg | 56.0Kg | 73.0Kg | |||
Weight(GW Kg) | 43.0Kg | 57.0Kg | 74.0Kg |
