Hot Sale 48V 100Ah Rack Mounted Rechargeable Solar Battery Off Grid Power Supply With Built-in LiFePo4 Lithium Ion 36Ah

2 pieces
MOQ
Hot Sale 48V 100Ah Rack Mounted Rechargeable Solar Battery Off Grid Power Supply With Built-in LiFePo4 Lithium Ion 36Ah
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: TP1236
Battery Type: LiFePO4
Nominal Voltage:: 12.8V
Nominal Capacity:: 36Ah
Cycle Life:: >2000 Cycles @0.5C 100%DOD
Energy:: 460.8Wh
Cell & Method:: 32700-4S6P
Dimensions (mm.):: 198*170*166
Weight (kg.):: Approx.4.1Kg
Plastic Case:: ABS
Certification:: CE,FCC
Supply Ability:: 100000 Sets Per Month
Basic Infomation
Certification: CE,FCC
Model Number: TP1236
Payment & Shipping Terms
Packaging Details: Packaging Details: International Standard seaworthy packing 1.Each battery single packing, Cartons stand on the pallet and protected by the waterproof plastic film. 2.Customized packing accepted
Supply Ability: 1000 Piece/Pieces per Month
Product Description
Products Description
Charactristics
Nominal Voltage
12.8V
Nominal Capacity
36Ah
Energy
460.8Wh
Cell & Method
32700-4S6P
Internal Resistance
≤60mΩ
Cycle Life
≥2000 cycles @0.5C 100%DOD
Standard Charge
Charge Voltage
14.6±0.2V
Charge Mode
CC(0.2C)/CV(14.4V)
Charge Current
6A
Max Charge Current
30A
Standard Discharge
Continuous Current
40A
Max Pulse Current
100A(＜10s)
Environmental
Charge Temperature
0℃ to 45℃（32F to 113F)）
Discharge Temperature
-20℃ to 60 ℃（-4F to 140F）
Storage Temperature
0℃ to 45℃（32F to 113F）
Mediancal
Plastic Case
ABS
Dimension(mm)
198*170*166
UN box(mm)
420*300*305(2PCS)
Net Weight(kg)
8.1 ± 5% (2PCS)
Gross Weight(kg)
9.8c± 5% (2PCS)
Terminal
M6
* Automotive grade cells:
Lithium iron phosphate batteries have exceptional quality since they are manufactured by Automotive Grade LiFePO4 Cells with higher energy density, more stable performance & greater power. Wider application range and higher safety factor.
* Broad operating temperature range,Effective protection:
12.8V 100AH LiFePO4 battery Operating Temp: Charge: 0°C~45°C; Discharge: -20°C~60°C. Our battery is IP65 waterproof, setting you free from worrying to install it indoors or outdoors.
* Safety management system, More safety, stable performance:
The built-in Battery Management System (BMS) protects your battery from Over Charge and Discharge, Over Current, Short-Circuiting,as well as Low and High Temperatures for increased performance and longer life.
* Deep cycle LiFePO4 battery:
Our lithium iron phosphate batteries have excellent 4500-5000 cycles and up to 3 years of service life. Compared to other LiFePO₄ batteries on the market, Our LiFePO4 rechargeable battery is perfect for campers, Home Energy Storage and Off-Grid Applications,etc.
* High-quality materials, Environment friendly:
Made from 100% safe, nontoxic, not hazardous energy, LiFePO4 battery has higher chemical stability, is not prone to thermal runaway, and will not overheat or catch on fire even if punctured. With no acid in the battery, you're able to safely mount in any position.
Applications:
●Engine Starting Battery
* Mobility cart,Tourist car, Marine,Golf troller,Golf car, E-Wheel chair, Caravan,E-bike, RV(Recreati&a Vehicle), AGV(Automated
Guided Vehicle), E-truck, E-sweeper, Floor cleaner, Boat & Fishing, foot travel trailer, etc.
* Intellectual Robots,
* Power tools: electric drills, toys, electric riding toys,
* Outdoor Emergency Power,Solar-Wind Power System, Power Backup,
* On/Off -grid Solar, City grid,
* Back-up System and UPS,Telcom Base, CATV system, Computer Server Center, Medical Instrumnt, Military Equipment
Details Images
1 Q:Can I get a solar generator power station sample? A:Yes, please leave your contact information and our sales manager will contact you soon.
2 Q:What kind of certificates your solar generator power station products have? A:Bluetti solar generator power station products have acquired UN38.3, CE, FCC, UL and PSE
certificates, which is able to satisfy most country’s importing requirements.
3 Q:Can you supply OEM &ODM service ? A:Yes, we supply OEM &ODM service,but there is a minimum order quantity required.
4 Q:Can I customize solar generator power station products? A:Yes. Let me know the specific customization requirements and I will get back to you as soon as
possible.
5 Q:What can solar power station power? A:The solar power station can power most of the home appliances, it also depends on the output
power of the power stations.

6 Q:Can you supply solar panels? Can you recommend? A:Yes, we supply suitable solar panels.
7 Q:How long is the warranty? A:Our warranty is from 2-5 years.
8 Q:How do you provide after-sales service? A:We provide spare parts for replacement of defective products.
9 Q:How long is the delivery time of your portable power stationproducts? A:We can ship in 3 days if ship from oversea warehouse.
10 Q:How do you ship your solar generator power plant products？ A:We have long-term cooperated forwarders who are professional at battery shipment.
