Home /Products/Solar Power Inverters/China Wholesale Price Home Solar Power System Growatt Solar Inverter 2kw 3kw 5kw Off Grid Inverter Smart 24V/48V DC AC Solar System Solar Inverters

China Wholesale Price Home Solar Power System Growatt Solar Inverter 2kw 3kw 5kw Off Grid Inverter Smart 24V/48V DC AC Solar System Solar Inverters

1 piece
MOQ
China Wholesale Price Home Solar Power System Growatt Solar Inverter 2kw 3kw 5kw Off Grid Inverter Smart 24V/48V DC AC Solar System Solar Inverters
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: SPF 2000TL HVM-24
Input Voltage: 48VDC
Output Voltage: 220V/230V/240VAC(+/-10% RMS)
Output Current: 50A
Output Frequency: 50Hz/60Hz
Output Type: Single
Size: 315/400/130mm
Type: DC/AC Inverters
Inverter Efficiency: 93%
Weight: 8kg
Product Name: Solar Inverter
Application: Solar Power System Home
Protection: Overload
Keyword: Inverter Solar
Waveform: Pure Sin Wave
Inverter Type: Off-grid Power Inverter
Basic Infomation
Model Number: SPF 2000TL HVM-24
Payment & Shipping Terms
Supply Ability: 10000 Piece/Pieces per Month
Product Description
Specification
Datasheet
SPF 2000TL HVM-24
SPF 3000TL HVM-24
SPF 2000TL HVM-48
SPF 3000TL HVM-48
SPF 5000TL HVM/HVM-P
Battery Voltage
24VDC
48VDC
48VDC
Battery Type
Lithium/Lead-acid
Lithium/Lead-acid
Lithium/Lead-acid
INVERTER OUTPUT
Rated Power
2000W
3000W
2000W
3000W
5000W
Parallel capability
NO
NO/YES,6 max
Surge Rating
4000VA
6000VA
4000VA
6000VA
10000VA
Waveform
Pure sine wave
Nominal Output Voltage RMS
230VAC(+/-5% RMS)
Output Frequency
50Hz/60Hz +/-0.3 Hz
Transfer Time
10ms typical，20ms Max
SOLAR CHARGER
Maximum PV Charge Current
50A
30A
80A
Maximum PV Array Power
1500W
1800W
4500W
Number of independent MPP trackers/
strings per MPP tracker
1/1
1/1
MPPT Range @ Operating Voltage
30~80VDC
60~115VDC
Maximum PV Array Open Circuit Voltage
102VDC
145VDC
Maximum Efficiency
98%
AC CHARGER
Voltage
230VAC
Selectable Voltage Range
170~280VAC(for personal computers); 90~280VAC(for home appliances)
Frequency Range
50Hz/60Hz (Auto sensing)
Maximum Charge Current
30A
50A
15A
60A
MECHANICAL SPECIFICATIONS
Protection Degree
IP20
Dimensions (W/H/D)
315/400/130mm
350/455/130mm
Net Weight (Solar CHG) kg
8
8.5
8
8.5
11.5
OPERATING ENVIRONMENT
Operation Temperature Range
0°C to 55°C
Please contact us for more technical data ,if necessary.
Trust us ! You will get low price and high quality ,also good service ! Welcome to inquire!!
FAQ
1、who are we? A: Baoding Daran New Energy Technology Co., Ltd. is a professional operating a variety of inverters, connectors, solar panels, monitoring equipment and other solar products, has a complete and scientific quality management system. 2、how can we guarantee quality? A: Always a pre-production sample before mass production; Always final Inspection before shipment 3、what can you buy from us? A: solar inverters, connectors, solar panels, monitoring equipment and other solar products 4、Why should you buy from us instead of other suppliers? A: We have been focusing on this field for many years. With advanced equipment, scientific management technology and excellent quality control, we have won customers all over the world. 5、How’s the delivery time? A: It depends on the quantity you need. 6、How do you make our business long-team and good relationship？ A: We keep good quality and competitive price to ensure our customers benefit.
