Home /Products/Off Grid Solar Inverters/factory supply white color MPPT SCC 120-500VDC Off Grid Solar Inverter with parallel operation 472mm*297mm*129mm

factory supply white color MPPT SCC 120-500VDC Off Grid Solar Inverter with parallel operation 472mm*297mm*129mm

1 piece
MOQ
factory supply white color MPPT SCC 120-500VDC Off Grid Solar Inverter with parallel operation 472mm*297mm*129mm
Features Gallery Product Description Request A Quote
Features
Specifications
Model Number: VEK 02
Input Voltage: 230Vac
Output Voltage: 230Vac
Output Current: 80A
Output Frequency: 50Hz/ 60Hz
Output Type: Single
Size: 472mm*297mm*129mm
Type: DC/AC Inverters
Inverter Efficiency: 97%
Certificate: CE
Warranty: 12 Months
Weight: 10.5kg
Basic Infomation
Certification: CE
Model Number: VEK 02
Payment & Shipping Terms
Supply Ability: 2000000 Piece/Pieces per Year
Product Description
Product Description
Features
Pure sine wave output. Output power factor 1.0 .
Programmable supply priority for PV , battery or Grid Use with lithium batteries
User-adjustable charge current and voltage Parallel operation up to 6 units
Wide PV input range (120Vdc -500Vdc), 110A MPPT SCC PV and electricity complementary
Working without batteries in sunny day WiFi Monitoring Function (optional)
Anti-dusk kit for harsh environment(optional)
LCD remote control with 5/10/20 meters wire (optional)
Details Images
Specification
MODEL
MPS-5500HP
Rated Power
5500VA/5500W
INPUT
Voltage
230VAC
Selectable Voltage Range
170-280VAC(for personal computers)
90-280VAC(for home appliances)
Frequency Range
50Hz/60Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt.Mode)
230VAC±5%
Surge power
11000VA
Efficiency(Peak) PV to INV
97%
Efficiency(Peak) BAT to INV
94%
Transfer Time
10ms (for personal computers)
20ms (for home appliances)
Wave form
Pure Sine Wave
BATTERY & AC CHARGER
Battery Voltage
48VDC
Floating Charge Voltage
54VDC
Overcharge Protection
63VDC
Maximum charge current
80A
SOLAR CHARGER
MAX.PV Array Power
6000W
MPPT Range@ Operating Voltage
120-500VDC
Maximum PV Array Open Circuit Voltage
500VDC
Maximum Charging Current
110A
Maximum Efficiency
98%
PHYSICAL
Dimension.D*W*H(mm)
472*297*129
Net Weight (kgs)
10.5kg
Communication Interface
RS485/RS232(Standard)
 LCD remote/WIFI(Optional)
OPERATING ENVIRONMENT
Humidity
5% to 95% Relative Humidity(Non-condensing)
Operating Temperature
0°C to 55°C
Storage Temperature
-15°C to 60°C
Packing & Delivery
Certifications
Company Profile
Shenzhen Weianke Electronics Co., Ltd. estabished in 2005, has been focused on energe industry. We've not only been doing 7 years overseas business, but also been supplying the UPS batteries for the equipment of pubic security organ, some banks, social issurance department etc. in mainland China. And now our solar inverters have been sold to allover the world, we have 15000 square meters plant, including 4 SMT lines and 8 assembling lines to produce solar inverter and batteries. We have got ISO9001 certificate for the plant and have CE, EMC,SGS etc reports for the products. Look forwarder to being your reliable partner.
FAQ
1.Who are we?
A: We are a factory in Shenzhen, Guangdong, China, start in energy industry from 2015. Previously we provided UPS power supply, and now our main product is Solar inverter.
2.What's the lead time of delivery？
A: We have stocks for some models. So it will be very fast like 2-3days after confirmation to make the delivery for stocks.
3.What's MOQ?
A: 1-49pcs for samples, 50pcs more for mass production.
4.Do you offer customized service？
A:Easy for us to make packing and logo customized. For products spec customized, need to further check the referred parameter.
5.How about the warranty?
A: We will provide main parts spare parts for mass production order, and will always provide on-line technical support.
